MXLED700/500 Pilot Edition Surgical Shadowless Lamp Product Description

1. Lamp head design compliant with laminar flow requirements:
The lightweight and slim lamp body design achieves a maximum thickness of only 60mm, better meeting the
purification requirements of laminar flow operating rooms; it occupies minimal space with a wider field of view; the
integral die-cast aluminum construction ensures excellent heat dissipation and an elegant appearance. 2、LCD touch screen makes operation more convenient
Equipped with an LCD touch screen control system, it enables effortless operation of surgical lights and switching
between various illumination modes. The system supports 10-level illuminance adjustment and 5-level color
temperature modulation according to different surgical requirements, along with free switching among six
illumination modes: deep cavity, superficial, normal, orthopedic, cardiac, and gynecological. This design meets
diverse lighting needs for various surgeries and personalized requirements of surgeons, enhancing surgical precision
and efficiency while providing more convenient operation. 3、Intelligent Multi-layer Spot Superposition Technology Advanced Photoelectric Sensing and Inter-control
System
The intelligent multi-layer large-area light spot design provides enhanced focus with reduced glare; the biomimetic
1
Shandong Mingxu Medical Equipment Co., Ltd. compound eye structure features a large 60mm-diameter lens for broader light coverage. Additionally, the
light-shadow sensing technology is employed, where LED beads in other areas automatically compensate for
illumination when light is obstructed by the surgeon or surgical instruments. Even under 80% occlusion, the
illuminance remains above 76% of the unobstructed level, ensuring maximum illumination to achieve shadow-free
surgical outcomes and guaranteeing safe procedures. The interlocking function of the main and auxiliary lights allows the physician to control one lamp while
simultaneously operating the other. 4、Excellent optical parameters and precise focusing system
Utilizing the 10th-generation medical-grade LED cold light source from the world-renowned brand OSRAM, the
product achieves superior optical performance. Coupled with a meticulously designed optical arrangement, it
ensures uniform illumination, rounded light spots, outstanding color rendering index, high shadow-free rate, and no
glare. This not only provides surgeons with a safer and more comfortable lighting environment but also safeguards
their eyes, enhances tissue visual resolution, and reduces fatigue. The system consists of 27 independently replaceable LEDs, each equipped with a lens-refractive light-emitting
system. The overall design of the LED head focuses the light beam into a high-brightness, uniform light column, ensuring a soft and uniform deep-focus effect to meet the surgical requirements for high-brightness and high-depth
illumination. The three-stage electronic focusing function allows for real-time adjustment of light focus according to surgical
requirements, ensuring clear surgical visualization and reducing procedural risks. 4. Easily detachable aluminum alloy disinfection handle
The quick-release mechanism is constructed with high-end medical-grade aerospace aluminum material, featuring a press-type plug-and-play design for convenient and simple operation, meeting the sterile operation
requirements of clean operating rooms. 5. Excellent suspension, balance, and linkage systems
The lightweight imported technology balance arm suspension system features six articulated joints in
coordinated linkage, with a 360-degree omnidirectional design that accommodates various heights, angles, and
1
Shandong Mingxu Medical Equipment Co., Ltd.
1
patient positions during surgical procedures, ensuring convenient mobility and precise positioning.
