Navigational MDT-I Gynecological Operating Table Electric Operating Table Obstetric Delivery Bed

1. Equipped with an advanced linear actuator featuring high load capacity, low noise, and superior safety and reliability. Driven by a fully electric mode, it delivers rapid, intelligent, and high-precision operation with enhanced safety and reliability. The
system integrates production bed and inspection bed functions to meet comprehensive
operational requirements. 2. The surgical table features two independent
control systems: a manual controller and a pedal
controller. 3. It allows adjustment to various positions, including supine and Trendelenburg positions;
4. The worktop height adjustment
accommodates both seated and standing positions for medical practitioners;
5. The concealed auxiliary table facilitates operation by medical staff, featuring a
concave design that enables closer contact with the parturient, thereby enhancing
nursing efficiency. 6. Three distinct leg supports and footrests provide convenience for patients with
special needs;
7. The integrated lumbar support with the back pad provides comfortable posture
support for postpartum women. 8. The handrest plate can also be abducted, making it suitable for maintaining a
relaxed posture; it can likewise be erected to serve as a guardrail; when not in use, it
can be positioned at its lowest level without requiring disassembly. 9. The obstetric handle features a streamlined design with ergonomic grip, allowing it
to be easily pushed forward for storage when not in use. 10. The seat board can be tilted downward, providing convenient access for the
parturient at its lowest position;
11. Equipped with an easy-to-operate mechanical brake, the brake feet remain in
contact with the ground during braking, ensuring stable and reliable operation of the
operating table, which can be securely fixed to any flat or inclined surface with ease. 12. Equipped with two directional wheels and two swivel wheels, the obstetric bed
facilitates easier movement and position adjustment;
13. Equipped with a high-capacity built-in battery ensures uninterrupted operation of
the obstetric bed, along with an energy level low warning function.
technical parameter ：
order
numbe
r
project content remarks
1 Total bed length 1900±20mm
2 Bed width 700±15 mm or 850±15 mm Two options available
3 Elevation lift height
Minimum: 650 ± 20 mm;
Maximum: 1000 ± 20 mm
motor-driven
4 Auxiliary board length 450±10mm
5 Forward and rear tilt angle
The forward tilt angle is ≥25
±2° Rearward tilt angle ≥15±2° motor-driven
6 Back panel fold angle 0±2°—75±5° motor-driven
7 Rated load capacity 185Kg
8 Waste basin dimensions 500*300*200mm
9 Auxiliary plate load-bearing ≥20Kg
