R100ST AUTO CPAP Positive Airway Pressure Machine Respiratory Therapy Cpap-machine -

Product Description

Introduction
It is suitable for the treatment of patients with snoring and sleep apnea hypopnea syndrome, and can also be used for the treatment of sleep apnea combined with chronic obstructive pulmonary disease (COPD) and obesity hypoventilation syndrome (OHS). It is suitable for family use, clinic use and hospital use.
It has exquisite and compact structure design and is easy to carry. It features friendly human-computer interaction, simple function operation, easy to use. Its main functions include:
Six therapy modes (CPAP, S, T, ST, PAC and SVAPS), real-time therapy information display, data storage, breathing gas warming and humidifying, USB data transmission, real-time clock.

Product Functions
1)Smart start: after identifying the wearing status of the mask, it can automatically start / stop the therapy.
2)Event detection: automatically detect the breathing events, such as leak, hypoventilation, apnea and snoring index.
3)Auto switch: automatically trigger and switch inspiratory and expiratory pressure based on the breathing status.
4)Adjustable parameters: the parameters can be set by users, such as Ramp time, humidity Level (6 levels), rise time and trigger sensitivity.
5)Leak compensation: support the automatic leak compensation within a range.
6)Data storage: support multi-dimensional data storage and check function, such as respiratory events, treatment data.
7)Large screen display: display the real-time parameters and detailed therapy data.
8)Six therapy modes: CPAP, S, T, ST, PAC, SVAPS
SVAPS (Smart Volume Assured Pressure Support): by adjusting the pressure support, adjust the minute volume to the preset target to ensure the support of volume.
Backup rate function: when a continuous apnea occurs, it will simulate the user’s breathing rate to provide breathing support, and automatically stop after normal breathing.

Performance
Parameter Range
Operating Pressure CPAP： 4 cmH2O～20 cmH2O
S、T、ST、PAC、SVAPS：2 cmH2O～25 cmH2O
Accuracy：± (0.5cmH2O+4% actual reading)
Leakage flow 0 L/min～200 L/min
Minute ventilation volume 0 L/min～30 L/min
Tidal volume 0 mL～4000 mL
inspiratory time 0.1 s～4.0 s
inspiratory/respiratory ratio 1：50～2：1
respiratory rate 0 bpm～50 bpm
Ramp Time 0～45 min
SpO2 Measurement 0～100 %
PR Measurement 30～250 bpm
Noise normal operation (including humidifier) noise≤30 dB
Power 100 V-240 V,50 Hz/60 Hz,1.0 A-1.5 A

Accessories
Breathing tube (Breathing circuit)
Micro SD Card
SpO2 probe (Optional)
Mask
Power adapter
Air Inlet Filter Cotton
Portable bag
User Manual

Physical Specification
Dimensions： 275*170*145 mm
Breathing tube：Soft plastic, length is 1.8m, outlet complies with ISO5356.1 22mm conical joint
Weight（device and cleanable humidifier）：1600g
Work Environment：
a）Operating Temperature：+5 ℃～+40 ℃
b）Relative Humidity：10%～95%, non-condensing
c）Atmospheric Range (non-condensing)：700 hPa～1060 hPa

FAQ

1. Are you a manufacture or trader ?
—-We are a professional manufacture , we have our own produce team and sales team, we also provide one-stop service.
2. What’s your MOQ ?
—-For this product, MOQ is 1 unit.
3. How long is the warranty time ?
—-We supply 12 months warranty time ,during this time we will help you solve any problems.
4. Do you provide OEM/ODM Service ?
—-Yes, we provide this service to meet different requirements , different budget to all clients.
5. How are we going to install the equipment after purchasing ?
—-We will provide user manual comes with machine ,also professional installation video to help you .
6.What payment terms you support ?
—-We accept T/T, credit card ,Visa card, Paypal etc.
7. What is your delivery time ?
—-It depend on your qty,if we have it in stock ,we can ship in 3 days after receive deposit ,if we don’t have it in stock,normally production time is 7-10 working days .
8. Do you have CE and ISO certificate ?
—-Yes, most of our products have the CE and ISO certificate
